Honeywell 2TL1-2 DPST Toggle Switch – MS24524-22

Honeywell MICRO SWITCH TL Series toggle switches are military qualified to MIL-DTL-3950, specifications for sealed toggle switches. Quality construction features include a bonded seal between the toggle lever and bushing, and between the cover and case.

The robust design of the TL Series toggle is well-suited for many military, aerospace and other demanding applications where reliability is essential. These applications include environments where the panels are subjected to mechanical shock, vibration, and temperature extremes as well as environments with dust, splashing or hose-directed water.

TL Series toggle switches offer a variety of circuitry and pole options to easily integrate into a number of applications. A long history in military and aerospace applications has shown the TL Series toggle switches provide reliable performance with long operating life under the toughest conditions.

Specifications:

• Part Number: 2TL1-2
• Mil-Spec Number: MS24524-22
• Double Pole Double Throw (DPST) Toggle Switch
• 2 Position; OFF – ON (Keyway – Opposite)
• Circuit(s) Made with Toggle At:
  • Keyway Position: OFF
  • Opposite Keyway: 2-3 & 5-6
• 4x 6-32 Screw Terminals (screws and lock washers are included) – 5 in/lbs max torque.
• 15/32-32 Mounting Bushing for a 12.4mm (.49″) Panel Cutout (locking ring, lock washer, and two hex nuts are included) – 10-15 in/lbs max torque.
• Electrical Rating: 20 amps up to 28 VDC
