Flame Retardant Silicone Flex Glass Sleeving – 6 AWG (4.22mm) x 10′

Flame Retardant Silicone Flex Glass (SF) sleeving is an extremely flexible braided fiberglass sleeve coated with a flame retardant elastomeric silicone rubber sheath.

The unique self-fitting construction allows Silicone Flex Glass sleeving to expand slightly for easy installation, and provides a snug fit for minimum movement and reduced internal
abrasion.

Silicone Flex Glass sleeving is rated to 392°F. (Class H), is abrasion resistant, and maintains its flexibility in low temperature environments. It is available in a very wide range of
sizes, and is ideal for use in appliance assemblies, wire harnesses, transformer leads, power supplies, motor coil, and heater leads.

Specifications:

• Nominal Diameter: 6AWG (0.166″) / 4.22mm
• Color: Black
• Operating Temps: -103°F to 392°F (-75°C to 200°C), Class H
• Grade A (8,000 V) MIL-I-3190/6

Notes:

 – This sleeving is nearly identical to the shiny sleeving found on many BMW O2 Sensor wires such as M54 Pre-Cat O2 wires in the transmission harness.

 – Sleeving will be sold as a continuous length. Each quantity ordered represents 10ft of sleeving. Example; 3x qty will equal 1, 30ft piece of sleeving.
